Olimpia Splendid's multi-purpose air-to-water heat pump, with R32 refrigerant, stands out for its ability to provide a single solution for the simultaneous management of cooling/heating and the production of high temperature DHW (up to 75°C), thanks to the patented Aquadue technology. The double refrigeration circuit allows, in fact, operation in parallel, without compromising the level of domestic comfort. Not only this: the possibility of storing DHW at high temperature can avoid the periodic use of anti-legionella cycles with the relative peaks in electricity consumption, as well as reducing the volume of the boiler by up to 30% for the same amount of DHW that can be delivered, thus obtaining a smaller overall size.
Energy efficiency class in heating medium climate up to: A+++ (35°C) e A++ (55°C)
Available powers: 10 powers with refrigerant R32 single-phase (4-6-8-10-12-14-16 kW) and three-phase (12-14-16 kW).
DHW (Domestic Hot Water) production at a high temperature, up to 75 ° C.
DHW management: a group of water-water heat pumps integrated in the indoor unit provides domestic hot water at a high temperature regardless of external weather conditions.
Continuous absolute availablity of DHW: guaranteed by the redundance of the double refrigerating circuit system.
Antilegionella cycles avoidable using the refrigeration cycle at high temperature. 2-stage electric heater: single or double strength activation to support the heat pump through a simple configuration of the electronic control. Each stage is activated according to the actual need of thermal power in order to optimize power consumption.
Configurable points: two set points in cooling mode Three set points in heating mode (one of them for DHW): the set points are also selectable
by remote contact.
Weekly programmer DHW, holidays and daily with night mode.
Climatic curves with outside air temperature sensor: two curves are available, one for cooling and one for heating. Climatic curves allow you to modify system water temperature supply depending on climate conditions, adapting the heat requirements of the building in order to obtain
energy savings.
Refrigerant gas: R32* for the reversible circuit dedicated to air-conditioning and R134a** for the high temperature circuit dedicated to DHW
production.
* Non hermetically sealed equipment containing fluorinated gas with GWP equivalent of 675 (R32)
** Non hermetically sealed equipment containing fluorinated gas with GWP equivalent 1430
